Model

UD-3218LE

UD-3212LD

Printhead

Epson DX5

Number of printhead

4 Heads

2 Heads

Maximum print width

3,200mm

Maximum media width

3,300mm

Print Speed (m2/h)

Rough Draft 2Pass

122

--

Draft 3Pass

99

44

Standard 4Pass

60

33

Quality 6Pass

46

22

High quality 8Pass

32

16

Back-lit 12Pass

23

11

Ink

Type

Water based/ Eco solvent ink

Color

4 Colors (CMYK)

Capacity

1L per main tank of each color

Ink Supply System

Auto ink supply system

Media Type

Ceilling film, Vinyl, PS Board, KT Board, PVC Foam Board, Window Flim, Polyester, Flex, Back-lit Film, etc

Auto Media Feeding System

Equipped (Max. Media Weight 80kg)

Equipped (Max. Media Weight 40kg)

Auto Cleaning System

Anti-clogged Flash Function & Capping System

Pre-heating & Drying System

Equipped

Clamp

Equipped

Print Interface

USB 3.0

USB 2.0

Printhead Height

1.5 to 10 mm from Media

2 to 10 mm from Media

RIP Software

Maintop

Input Power

AC 220V, 50Hz/60Hz

Operating Environment

Humidity

20-80% (Recommend 40-60%)

Temperature

 15-35°C(Recommend 20-32°C)

Machine Dimension / N.W

L4,480 x W920 x H1,225mm / 390KG

L4,500 x W905 x H1,260mm / 304KG

Package Dimension / G.W

L4,830 x W1,150 x H970mm / 633KG

L4,590 x W1,100 x H940mm / 547KG
